Home > Stainless Steel Channels
Andre Stainless, Pulau Ujong, Singapore, is a reliable producer and supplier of Stainless Steel Channels to meet extensive structural and industrial demands. We provide channels in grades such as 304, 316, and 201 for their durability, corrosion resistance, and superior bearing strength. They come in U, C, and custom shapes, and our stainless steel channels find extensive usage in building construction, machinery structures, equipment enclosures, and architectural structures. With sophisticated forming techniques, precision finishes, and an emphasis on quality, we produce consistent, high-performance channels engineered to satisfy contemporary engineering, design, and project requirements.
Our channels in stainless steel are produced from 16–18% chromium and 8–10% nickel alloy in grade 304, utilizing 2–3% molybdenum in grade 316 for added corrosion resistance. These sheets have tensile strength of 520–620 MPa, yield strength of 205–310 MPa, and high ductility and toughness. Channels have stability in dimensions under stress, are weldable, and can be rolled into desired shapes. We provide both cold-rolled and hot-rolled types to suit structural, mechanical, as well as decorative purposes.
| Standard | ASTM A276, ASTM A479 / ASME SA276, ASME SA479 |
| Condition | HRAP |
| Size Range | Base: 80 to 150 mm Side: 40 to 75 mm |
| Thickness | 5 to 6 mm (depending on size) |
| Grades | 304, 316 |
| Processing | Bar cutting |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
Andre Stainless supplies high-quality materials with a focus on strict testing procedures. All our products go through rigorous testing like hardness testing, chemical analysis through spectro analysis, PMI testing, tensile testing, micro and macro structural tests, pitting resistance, and IGC testing. We assure you of superior performances by these thorough checks. With our quality commitment, we also give all the commercial invoices, packing lists with net and gross weights, box numbers, labels, and a Certificate of Origin legalized or attested by the Chamber of Commerce or Embassy. Third-Party Inspection Certificate will also ensure that the customers are satisfied with our SS Channel’s pricing and delivery.
Choose stainless steel channels based on your project’s required strength, corrosion resistance, and environmental conditions. Consider factors like size, grade, and finish to ensure compatibility with your application.
Yes, we provide stainless steel channels in custom sizes and polishes based on your specifications. For more details mail us on sales@andrestainless.com
Stainless steel channels are universal structural members employed in building support, wall frames, equipment platforms, and conveyor systems. In seacoast and offshore applications, 316-grade channels offer exceptional saltwater corrosion resistance. The channels are also best suited for architectural applications, such as curtain wall systems, trims, and railings. In food processing and pharmaceutical applications, they are used for their hygienic, non-reactive surfaces. Andre Stainless supplies bespoke-fabricated channels with customized lengths, profile forms, and surface finishes like satin, brushed, or polished for compatibility with varied design, structural, and operational demands.
