Home > Stainless Steel 304/304L Angles
Andre Stainless is a superior stainless steel manufacture and supplier operating in Pulau ujong, Singapore. Operating on the criteria of excellence, innovation, the company specializes in offering high-performance stainless steel angle bars 304/304L with the highest class durability, rust resistance, and accuracy. Made from the premium-grade stainless steel material, 304/304L angles satisfy international standards so as to endure performance in highly challenging environments due to their broad usage in constructing, industrial structures, and frameworks. backed by a devoted team and equipped with cutting-edge manufacturing facilities, now provides customers from numerous industries with high-quality solutions in a reliable manner and so cements its place within the market for stainless steel.
The Stainless Steel 304/304L Angles consist of 18% chromium and 8% nickel, with the 304L version featuring a lower carbon content that enhances its weldability. These angles boast impressive mechanical properties, including a tensile strength of about 515 MPa and a yield strength of 205 MPa. The material also offers good elongation (at least 40%) and a Brinell hardness of 201. The lower carbon content in 304L helps reduce carbide precipitation during welding, which ensures long-lasting durability and corrosion resistance, particularly in tough or high-temperature settings.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
At Andre Stainless, all stainless steel 304/304L faces are rigorously tested to ensure quality and reliability. Certified to international standards, our products come with material test reports (MTR), third-party inspection certificates, and compliance with ASTM/ASME specifications. This ensures optimal performance, security and customer reliability in any application.
Stainless Steel 304/304L angles are L-shaped structural sections offering high strength, corrosion resistance, and durability. They are used in construction, manufacturing, and architectural applications for support and reinforcement.
Stainless Steel 304/304L equal angles feature two legs of the same length, forming a 90-degree angle. They provide strong, durable support and are widely used in construction and structural applications.
Stainless Steel 304/304L unequal angles have legs of different lengths, forming a 90-degree angle. They offer versatile support and reinforcement in construction and industrial applications, with high strength and corrosion resistance.
Stainless Steel 304/304L L angles are L-shaped structural components used for framing and support. They provide high strength, durability, and corrosion resistance, suitable for construction, manufacturing, and architectural applications.
SS 304/304L T-bar angles are stainless steel sections with a T-shaped profile. They provide robust support and stability for structural and framework applications, offering high strength, durability, and corrosion resistance.
Stainless Steel 304/304L corner angles are L-shaped sections designed to reinforce and join corners. They offer high strength, durability, and corrosion resistance, ideal for construction and architectural applications.
Thanks to their strength, corrosion resistance, and ease of fabrication, Stainless Steel 304/304L Angles are widely utilized across various industries. You can often find them in structural frameworks, support brackets, and reinforcing components for construction and infrastructure projects. They’re also used in creating frames, racks, and equipment for the food processing, chemical, and marine sectors. Their ability to endure corrosive environments makes them ideal for outdoor applications and areas with high humidity. Plus, their formability and weldability make them a great choice for architectural and decorative uses.
