Andre Stainless is your go-to manufacturer and supplier of Stainless Steel 316/316L Angles right here in Pulau Ujong, Singapore. We pride ourselves on delivering top-notch products that are perfect for both industrial and architectural needs. Our SS 316/316L angles are celebrated for their outstanding corrosion resistance, particularly in challenging chloride and marine environments, making them a fantastic choice for coastal and chemical processing applications. With a strong commitment to quality, we provide precision-finished angles that adhere to international standards and meet our clients’ specific requirements. Thanks to our cutting-edge manufacturing technology and a talented team, Andre Stainless guarantees consistent product quality, timely deliveries, and competitive pricing for projects across a variety of industries.
When it comes to composition, Stainless Steel 316/316L Angles contain 16–18% Chromium, 10–14% Nickel, 2–3% Molybdenum, and low carbon content (especially in 316L), which boosts their corrosion resistance and weldability. These alloys boast impressive mechanical properties, including a minimum tensile strength of 485 MPa, yield strength of 170 MPa, and an elongation of 40%. The inclusion of molybdenum enhances their resistance to pitting and crevice corrosion, making these angles perfect for harsh and corrosive settings.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
We conducts a strict quality test and obtains certifications to guarantee the best Stainless Steel 316/316L Angles in terms of strength, corrosion resistance, and accuracy. Each product batch is certified for compliance with international standards and offers clients full assurance in terms of reliability, performance, and conformity to industrial needs for a variety of uses.
Stainless Steel 316/316L angles are L-shaped structural components known for their excellent corrosion resistance, strength, and durability. They are used in marine, chemical, and high-temperature applications for support and reinforcement.
Stainless Steel 316/316L equal angles have two legs of the same length, forming a 90-degree angle. They offer high strength and corrosion resistance, ideal for structural support in demanding environments.
Stainless Steel 316/316L unequal angles have legs of different lengths, creating a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L L angles are L-shaped structural components offering high strength, durability, and superior corrosion resistance. They are used for framing and support in marine, chemical, and high-temperature environments.
SS 316/316L T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are ideal for structural and framework applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L corner angles are L-shaped sections designed for reinforcing and joining corners. They offer high strength, durability, and excellent corrosion resistance, making them suitable for construction and architectural applications.
You’ll find Stainless Steel 316/316L Angles widely used in marine, chemical, pharmaceutical, and food processing industries, thanks to their remarkable resistance to corrosion and high temperatures. They’re commonly utilized in structural frameworks, support brackets, equipment frames, reinforcement applications, and architectural components. The low carbon variant, 316L, is particularly favored in welded structures as it reduces the risk of carbide precipitation. These angles are ideal for coastal construction, tank fabrication, and cleanroom environments where hygiene and durability are paramount. Plus, their aesthetic appeal and strength make them a great choice for architectural and decorative applications.
