Andre Stainless is a well-respected manufacturer and supplier of top-notch stainless steel products, proudly based in Pulau Ujong, Singapore. They specialize in Stainless Steel 310/310S Forged Fittings, delivering precision-engineered fittings that adhere to industry standards. These forged fittings are commonly utilized across a variety of sectors, including chemical, petrochemical, and power industries. With cutting-edge manufacturing facilities and a strong commitment to excellence, Andre Stainless guarantees that their stainless steel products offer outstanding performance, corrosion resistance, and durability. The company takes great pride in ensuring customer satisfaction, providing customized solutions to meet the diverse needs of clients in Pulau Ujong and beyond.
Stainless Steel 310/310S is primarily made up of iron, with notable amounts of chromium (25-27%) and nickel (19-22%) that contribute to its excellent oxidation resistance and high-temperature performance. The 310S variant has a low carbon content, which enhances its weldability. In terms of mechanical properties, it boasts high tensile strength ranging from 515 to 700 MPa, along with a yield strength of 205-345 MPa. This material also demonstrates good creep strength at elevated temperatures and maintains its structural integrity even under extreme thermal conditions, making it perfect for high-temperature applications.
Specifications : ASTM A182 & ASME SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24.00 – 26.00 | 0.10 max | 19.00 – 21.00 | 54.7 min |
| SS 310S | 0.08 max | 2.0 max | 1.00 ma | 0.045 max | 0.030 max | 24.00 – 26.00 | 0.75 max | 19.00 – 21.00 | 53.095 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
Contact us to get a quick quote for your requirement.
We ensures that it has the high quality standards with respect to Stainless Steel 310/310S forged fittings by using rigorous testing and certification processes. Every product under goes detailed check-up including dimensional checks, mechanical property tests, and assessment of corrosion resistance. Our fitting is certified for relevant industry standards, which guarantees superior performance and reliability across various applications.
These fittings are highly resistant to oxidation and corrosion at elevated temperatures. They are designed for high-pressure applications and come in various sizes typically ranging from 1/2 inch to 4 inches. Socket weld fittings are ideal for applications requiring a strong, leak-proof connection.
Threaded fittings in SS 310 offer excellent resistance to oxidation and corrosion, especially in high-temperature environments. Sizes generally vary from 1/8 inch to 4 inches. They are used for connecting pipes with threads, making them suitable for pressure-tight joints.
These elbows provide excellent corrosion resistance and are ideal for applications involving high temperatures. They are available in sizes from 1/2 inch to 4 inches and are used to change the direction of flow in piping systems by 45 degrees.
Threaded tees made of SS 310 exhibit superior resistance to high-temperature oxidation and corrosion. Common sizes range from 1/4 inch to 4 inches. These tees are used to branch out pipelines and provide a secure connection in high-pressure systems.
Offering excellent corrosion resistance, threaded half couplings are used to connect two pipes in high-temperature applications. Sizes typically range from 1/8 inch to 4 inches. They are ideal for creating a connection in the middle of a pipe.
Socket weld crosses in SS 310S provide high resistance to oxidation and are used in high-pressure systems. They are available in sizes from 1/2 inch to 4 inches and allow for the intersection of four pipes, ensuring a robust connection.
The Stainless Steel 310/310S Forged Fittings produced by Andre Stainless in Pulau Ujong, Singapore, are extensively used in high-temperature settings. Their exceptional resistance to oxidation and corrosion makes them ideal for industries such as power generation, petrochemical, and chemical processing. Typical applications include furnace parts, heat exchangers, burner components, and reactor systems. These fittings are also employed in gas turbines, cement plants, and incinerators, where they endure thermal cycling, intense heat, and harsh environments. The durability and performance of these stainless steel fittings ensure they provide long-lasting reliability in demanding applications.
