Introducing Andre Stainless, a top-notch manufacturer and supplier located in Pulau Ujong, Singapore, specializing in high-quality stainless steel products like Stainless Steel 317L Bars. With a strong focus on precision engineering and customer satisfaction, Andre Stainless delivers corrosion-resistant bar solutions designed for tough industrial settings. These Stainless Steel 317L Bars are perfect for chemical, marine, and pharmaceutical applications, excelling in harsh corrosive environments. The company guarantees that every product adheres to strict international standards through thorough quality control and expert technical knowledge. With reliable service and a wide range of inventory, Andre Stainless caters to both local and global markets with durable and trustworthy bar solutions.
Stainless Steel 317L Bars are a type of low-carbon, molybdenum-bearing austenitic stainless steel, made up of about 18–20% chromium, 11–15% nickel, 3–4% molybdenum, and a maximum of 0.03% carbon. The low carbon content significantly boosts resistance to intergranular corrosion after welding. In terms of mechanical properties, 317L boasts a tensile strength of around 515 MPa, a yield strength of 205 MPa, and a minimum elongation of 35–40%. These bars also excel in creep and stress-to-rupture strength at high temperatures. The additional molybdenum enhances resistance to pitting and crevice corrosion, making them ideal for use in aggressive chemical and marine settings.
| Specification | ASTM A276, A479 / ASME SA276, SA479 |
|---|---|
| Standard | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Round Bars | Outside Diameter in the range of 4mm to 500mm |
| Bright Bars | Outside Diameter in the range of 4mm to 100mm |
| Hex Bars | 18mm – 57mm (11/16″ to 2-3/4″) |
| Square Bars | 8mm – 47mm (11/16″ to 1-3/4″) |
| Length | 1 to 6 meters, Custom Cut Length |
| Form | Round, Square, Hexagonal, Rectangular |
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | N |
| SS 317L | 0.03 max. | 2.00 max. | 0.75 max. | 0.045 max. | 0.03 max. | 18.0 – 20.0 | 11.0 – 15.0 | 3.0 – 4.0 | 0.1 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | ||
| Rockwell B (HR B) max | Brinell (HB) max | |||||
| 317L | 595 MPa | 260 MPa | 55% | 85 | 200 | – |
Contact us to get a quick quote for your requirement.
We ensures exceptional quality through rigorous testing and certification of stainless steel 317L frames. Each bar undergoes ultrasonic, hardness and tensile strength testing to ensure it meets industry standards. Certified to ISO 9001, EN10204 3.1/3.2, and NABL-accredited laboratory reports, our products guarantee durability, corrosion resistance and reliability for critical applications
Corrosion-resistant Stainless Steel 317L Round Bars come in various diameters, typically from 6mm to 300mm. Ideal for applications requiring high strength and resistance to chloride environments, these bars are used in chemical and marine industries.
Stainless Steel 317L Flat Bars are available in thicknesses from 3mm to 50mm and widths up to 300mm. These bars offer exceptional corrosion resistance, making them suitable for structural and industrial applications, including chemical processing.
Stainless Steel 317L Square Bars are produced in sizes ranging from 10mm to 100mm. Known for their durability and resistance to aggressive environments, they are ideal for use in manufacturing and construction where strength and corrosion resistance are essential.
Stainless Steel 317L Rectangular Bars come in custom sizes with typical thicknesses of 5mm to 50mm and widths from 20mm to 200mm. They are used in applications where strength and resistance to harsh conditions are critical, such as in marine and chemical industries.
Stainless Steel 317L Hexagonal Bars are available in dimensions from 10mm to 100mm across flats. Their unique shape and corrosion resistance make them suitable for applications in high-stress environments, including aerospace and marine sectors.
Stainless Steel 317L T-Bars are manufactured with standard dimensions, often ranging from 10mm x 10mm to 100mm x 100mm. These bars are used in structural and industrial applications where high resistance to corrosion and strength are required, such as in chemical processing plants.
Stainless Steel 317L Bars find extensive application in highly corrosive environments where exceptional resistance to chemical attacks is essential. In the chemical processing sector, they are utilized in piping systems, pressure vessels, evaporators, and heat exchangers that handle acids and chlorides. The pharmaceutical and food industries rely on them for equipment that demands hygienic and non-reactive materials. In marine and offshore applications, they are favored for their durability and resistance to harsh conditions.
